Q (50Hz)
|
110.0 – 1,500.0 (m³/h) |
|
H (50Hz)
|
110.0 – 400.0 (m) |
|
Type of bearing
|
Rolling element bearings |
|
Casing partition
|
Radially split |
|
Diffuser material (EN standard)
|
CC480K-GS, GJL 250 |
|
Drive frequency
|
50 Hz /60 Hz |
|
Type of drive
|
Electric motor, turbine, I.C. engine |
|
Drive voltage
|
Low voltage |
|
Type of first impeller
|
Closed / Radial |
|
No. of impeller entries
|
Single entry |
|
Other impeller types
|
Closed / Radial |
|
Impeller material (EN standard)
|
CC480K-GS, GJL 250 |
|
Type of installation
|
Long-coupled |
|
Type of coupling
|
Direct |
|
Type of lubrication
|
grease-/oil- and product lubrication |
|
Discharge casing material (EN standard)
|
GJS 400 |
|
Max. permissible fluid temperature
|
60.0 (°C) |
|
Nozzle position
|
Variable |
|
Maximum operating pressure
|
PN 16, PN 40 |
|
Pump set location
|
Dry installed |
|
Shaft material (EN standard)
|
1.4021+QT |
|
Stage casing material (EN standard)
|
GJS 400 |
|
Suction casing material (EN standard)
|
GJS 400 |
|
Suction characteristics
|
Non-priming |
|
Type of connection
|
Flange |
|
Type of discharge casing
|
Annular casing |
|
Type of stage casing
|
Stage casing without diffuser |
|
Type of suction casing
|
Annular casing |
|
Casing material (EN standard)
|
GJS 400 |
|
eClass assignment
|
36410100, 36410000, 36410101 |
|
Installation position
|
Horizontal |
|
Shaft seal type
|
Mechanical seal, Gland packing |
|
Main applications
|
Water |
|
Casing material
|
Nodular cast iron |
|
Maximum discharge-side pressure
|
40.0 (bar) |
|
Maximum drive rating
|
1500.0 (kW) |
|
Type of installation
|
Stationary |
|
Maximum speed of rotation
|
1750.0 (1/min) |
|
Pump size
|
DN 200, DN 250 |
